You can create a trigger with SQL Server Management Studio (SSMS) .
To use the Enterprise Manager to create triggers:
Right-click the name of the table that the trigger will be assigned to.
Choose the All Tasks | Manage Triggers menu option.
Enter the appropriate Transact-SQL statements in the Trigger Properties dialog box, shown below:
Microsoft SQL Server Management Studio (SSMS) 19.0.1
The image is a screenshot of the Trigger Properties window from an older version of SQL Server Management Studio (SSMS). It displays a skeleton Transact-SQL (T-SQL) trigger definition.
🟦 Extracted Transact-SQL Code:
CREATE TRIGGER [TRIGGER NAME]
ON [employees]
FOR INSERT, UPDATE, DELETE
AS
🔍 Explanation:
CREATE TRIGGER [TRIGGER NAME]: Defines the trigger name (placeholder used here).
ON [employees]: Specifies the table the trigger is associated with — in this case, the employees table.
FOR INSERT, UPDATE, DELETE: Indicates the trigger will fire on INSERT, UPDATE, and DELETE operations.
AS: Begins the trigger body (logic to be defined after this line).
Expansion of the previous trigger that enforces a specific business rule for the "employees" table. The business rule we’ll enforce is:
đź§ Business Rule:
(*) Prevent any employee from being assigned a salary greater than $250,000.
âś… Completed T-SQL Trigger:
CREATE TRIGGER trg_EnforceSalaryCap
ON employees
FOR INSERT, UPDATE, DELETE
AS
BEGIN
SET NOCOUNT ON;
-- Check for salary cap violation on INSERT or UPDATE
IF EXISTS (
SELECT 1
FROM inserted
WHERE salary > 250000
)
BEGIN
RAISERROR('Salary cannot exceed $250,000.', 16, 1);
ROLLBACK TRANSACTION;
RETURN;
END
-- Optional: Handle DELETE event, if needed
-- (In this case, no business rule on DELETE, but included for completeness)
END;
📝 Explanation:
`SET NOCOUNT ON`: Prevents extra result sets from interfering with application logic.
`inserted`: A virtual table representing new or updated rows.
`RAISERROR`: Generates a custom error message with severity level 16 (user error).
`ROLLBACK TRANSACTION`: Cancels the DML operation if the rule is violated.
The DELETE case is included in the trigger, but no specific logic is added—this can be customized later.
Creating Triggers
A trigger can be fi red for any combination of insert, update, or delete events. Triggers are
created and modifi ed with the standard DDL commands, CREATE, ALTER, and DROP, as follows:
CREATE TRIGGER Schema.TriggerName ON Schema.TableName
AFTER | INSTEAD OF [Insert, Update, (and or) Delete]
AS Trigger Code;
You can also create, view and modify triggers using Management Studio's Object Explorer, as shown in Figure 4-5.
Figure 4-5: Object Explorer lists all triggers for any table and may be used to modify the trigger using
the context menu.
SQL Server Management Studio (SSMS)
While SQL Server Management Studio (SSMS) provides a graphical user interface for many database administration tasks, including creating and modifying triggers, the actual definition and logic of the trigger are specified using Transact-SQL (T-SQL) statements within the SSMS query editor.
Here's why this is the case:
Granular Control: Triggers often involve complex business logic, conditional execution, and specific actions based on data changes. T-SQL offers the necessary control flow statements (like `IF`, `ELSE`), data manipulation language (DML), and system functions to implement this logic precisely.
Defining Trigger Options: Options like `FOR INSERT`, `FOR UPDATE`, `FOR DELETE`, `WITH ENCRYPTION`, `NOT FOR REPLICATION`, and the trigger code itself are all part of the T-SQL `CREATE TRIGGER` statement. SSMS provides the framework to execute this statement.
No Drag-and-Drop Logic: Unlike some visual programming tools, the core logic of database objects like triggers is defined through code. SSMS helps you write, execute, and manage this code.
Think of SSMS as the environment and the T-SQL as the language you use within that environment to define the trigger's behavior. You might use the SSMS object explorer to navigate to the table where you want to create a trigger and then right-click to select "New Trigger," but the window that opens will be a query editor where you write the T-SQL code for the trigger.
So, while SSMS simplifies the process of interacting with the database and managing objects, the power and flexibility to define the specific behavior of a trigger lie in the T-SQL you write.
It's interesting how even with graphical tools like SSMS, the underlying power and flexibility for database objects like triggers come from writing code in T-SQL. It allows for a level of precision that a purely visual interface might not be able to offer.
Creating triggers with Transact-SQL
To create a trigger with Transact-SQL, you will use the CREATE TRIGGER Transact-SQL statement.
The syntax for this statement is shown in the following series of images.
CREATE TRIGGER trigger_name
ON table
[WITH ENCRYPTION]
{
FOR trigger_type
[WITH APPEND]
[NOT FOR REPLICATION]
AS
{
IF UPDATE (column)
[[AND | OR] UPDATE (column)]
[...n]
IF (COLUMNS_UPDATED() {bitwise_operator} updated_bitmask)
{comparison_operator} column_bitmask
[...n]
trigger_code [...n]
}
}
The uploaded image contains a template structure for creating a trigger in Transact-SQL (T-SQL). Here's the extracted and formatted T-SQL syntax based on the image:
🔍 Explanation of Key Elements:
`CREATE TRIGGER trigger_name`: Initiates the creation of a trigger.
`ON table`: Specifies the target table.
`WITH ENCRYPTION`: Optionally encrypts the trigger definition.
`FOR trigger_type`: Defines the type of DML operation(s): `INSERT`, `UPDATE`, or `DELETE`.
`WITH APPEND`: Appends this trigger to existing ones (specific cases).
`NOT FOR REPLICATION`: Prevents trigger from firing during replication processes.
`IF UPDATE(column)`: Checks if a specific column was updated.
`COLUMNS_UPDATED()`: Bitmask-based check for updated columns.
`trigger_code [...n]`: Placeholder for the actual trigger logic.
1) trigger_name is the name of the trigger you are going to create. A trigger is a database object,
so it must have a unique name within the database
2) table is the name of the table on which you will create the trigger.
3) WITH ENCRYPTION encrypts the text so that it can not be read from the syscomments table.
4) trigger_type is the type of trigger you wish to create.
The type can be INSERT, UPDATE, or DELETE, depending on the type of trigger you are creating.
5) WITH APPEND is an optional statement that indicates to SQL Server that if a trigger of the same type already exists,
this trigger should be added.
6) NOT FOR REPLICATION indicates that any replication operations that affect data in the table should not fir the trigger.
7) column is used if you wish to test for a specific column to have data inserted or updated into it. Multiple columns can be specified.
8) Bitwise_operator, updated_bitmask, comparison_operator, and column_bitmask all are affected by the COLUMNS_UPDATED clause, which is used to test a bit-filed representing one or more columns that are updated.
The image displays a Transact-SQL (T-SQL) syntax template for creating a trigger in SQL Server. Here's the extracted and properly formatted T-SQL code based on the image content:
🟨 T-SQL Code from the Image:
CREATE TRIGGER trigger_name ON table
[WITH ENCRYPTION]
{
FOR trigger_type
[WITH APPEND]
[NOT FOR REPLICATION]
AS
{
IF UPDATE (column)
[[AND | OR] UPDATE (column)]
[...n]
IF (COLUMNS_UPDATED() {bitwise_operator} updated_bitmask)
{comparison_operator} column_bitmask
[...n]
trigger_code [...n]
}
}
đź§ Key Elements:
`CREATE TRIGGER trigger_name ON table`: Begins the trigger definition.
`WITH ENCRYPTION`: Optional—encrypts the trigger definition to hide it from users.
`FOR trigger_type`: Replace with one or more of `INSERT`, `UPDATE`, `DELETE`.
`WITH APPEND`: Optional—appends this trigger to an existing set of triggers.
`NOT FOR REPLICATION`: Prevents the trigger from firing during replication.
`IF UPDATE(column)`: Checks if the specified column was part of an `UPDATE`.
`COLUMNS_UPDATED()`: Returns a bitmask indicating which columns were updated.
`trigger_code [...n]`: Replace with the business logic to execute.
9)trigger_code is the Transact-SQL code that you will use to implement your business rules, using the INSERTED and
DELETED special trigger tables.
In the next lesson, you will learn how to create triggers that satisfy unique business rules.
